#HOW TO TAKE APART A LENOVO B590 BLUETOOTH#
Intel Dual Band Wireless-AC 3165 Wi-Fi card with Bluetooth 4.2 Remove one screw and unplug two antenna cables. The Lenovo Miix 520 comes with a Samsung 256GB PM961 PCIe NVMe M.2 SSD. Next, we will remove the SSD and wireless network card. The back of the heat sink, you can see the bottom of the copper tube is covered with black insulating paper, which can prevent the copper heat conduction to the SSD. Unscrew the five fixing screws around the cooling module to remove the cooling module. The top left is a pair of noise-canceling microphones The Micro SD card reader can be seen on the left side of the battery. Only five contacts can complete the signal transmission of the keyboard and the touch board at the same time. Under the battery we can see the contact of the magnetic keyboard, which is connected to the main board through a cable. It comes with a 7.68V, 38Wh, 4955mAh Li-ion battery. Remove all screws securing the battery and take out the battery. There is a spare part on the top left corner of the machine, which is supposed to be the 4G module, that is, the Miix 520 will also have a 4G version.īefore continuing to disassemble, we need to disconnect the battery connector. And a copper tube is passed directly above the SSD, so that the temperature of the copper tube is bound to raise the temperature of the SSD.Ī row of small holes below the volume buttons is actually the cooling vents on the other side. The volume of the loudspeaker is also not large, which is the most obvious problem of the internal structure of Miix 520.Īlso, the two copper tubes used only a fan to be responsible for the heat dissipation. The layout of the cooling modules is quite satisfactory, but there is a considerable spatial surplus around the battery. The two cables on the back of the screen are the display cable and the touch cable, and their circuit board is located in the lower right corner of the screen. When you split the screen assembly, the internal structure of the Miix 520 is unobstructed.
Before removing the screen, you need to disconnect two cables first. Remove the screws on both sides to remove the metal bracket, the bracket made of aluminum-magnesium alloy, while ensuring the lightweight but also take into account the strength.Īfter removing the screws that secure the back cover, carefully release all the snaps along the edge of the screen to separate the screen from the housing. Unscrew the screw on the LCD hinges, remove the cover, you can see there are three screws inside, a total of five screws to ensure that the LCD hinges and the metal bracket fixed firmly. Open the bracket you can see the screws, and this disassembly will start from here. The Lenovo Miix 520 review, please click here. It comes with up to 16GB DDR4 memory, maximum support 1TB SSD, these powerful configuration options have surpassed many of today’s thin and light notebooks. The Miix 520 equipped with the latest eighth-generation Intel Core processors. They hope that while ensuring the product light and portability, but also able to have high performance to meet the needs of the high-load office. The Lenovo Miix 520 2-in-1 laptop is designed to meet the needs of the mobile workforce. I will remove the display assembly to access the internal battery, RAM, SSD, Wi-Fi card, speaker, cooling fan, heat sink, and motherboard.
In this guide, I will disassemble a Lenovo Lenovo Miix 520 tablet.
